The Mobile Mini Stage consists of stage panels, stage side brace, stage adjustable legs and adjustable base.The height can reach from 1.5m to 2m height for outdoor concert events.
Item No :
KDT2-1212POrder(MOQ) :
1 piecePayment :
30% deposit, 70% balance before delivery goods.( standard goods)Product Origin :
ChinaColor :
Black color plywoodShipping Port :
Gunagzhou/Foshan/ShenzhenLead Time :
3-15 working daysWeight :
22kg for 1.22*1.22m panelHow to get a stage quotation form our sales team?
Application:
This 4x4 portable stage quality is commonly combined with Truss Stage Roof for temporary indoor and outdoor concerts events. if you install them correctly, the whole Potable Stage Systems can work as ballast for the roof.
Specification:
Item | 4*4ft Portable Stage |
Material | Aluminum Alloy 6061-T 6 |
Dimensions | 1.22*1.22m, 1.22*2.44m/ 4*4ft, 4*8ft |
Types | Rectangle, Square, Round, any shape. |
Leg Main tubes | 50 x 3 mm |
Stage Topping | 18 mm birch tree plywood board covered with a smooth anti-humidity layer phenolic resin, anti-slip, waterproof |
Loading Capacity | Max load:750kg /m² |
Height(adjustable) | 30-40cm, 40-60cm, 60-100cm, 80-120cm, 90-140cm, 100-150cm, 160-200cm. |
Min. height | 28cm |
Size | We can offer customized service. |
Ladder Shape frame make the stage legs much stabler and firmer. The stage height can reach 2m high. Fixing the adjustable height by pins and holes ensures the telescopic legs much safer.
The Platform Event stage one piece standard 4*4ft stage platform can hold 750kg and 4*8ft stage platform can hold 1500 kg on the whole Platform, and the pillars, side pannels , as well as the toppings are must be designed and produced to be capatable of supporting that weight. The heigher platform, the longer pillars and the side pannels designed to keep stability at the heighest level.
The DIY Portable Stage can be constructed into a variety of shapes and sizes of Stage Lighting Truss Systems. The system can be changed quickly and easily, often no need any tools.
How to assemble modular stage?
1. Put the 4 adjustable feet on the floor.
2. Put the 4 legs in the screw of the jacks.
3. Connect every 2 pillars with the side panels.
4. Put the stage topping inside the glooves formed by the 4 side panels.
5. Adjust the the whole stage until fixed without any loosing space then finished.
Event Stage Feature:
Fast Assembled and Disassembled
Waterproof and anti-slip foroutdoor and indoor concert events
Aluminum frame and lightweight for movable use
Adjustable Height from 30-200cm.
How to get a custom modular stage?
Step1: Check and measure the site, where the stage shall be set up;
Step2: To decided how large of areas on the site to be used for the stage;
Step3: To decided the stage shape;
Step4: Determine the exactly length, depth and height of stage.
Step5: then let our sales know your requirements.
Contact us now! Just let us know you from our website then we can make your logo on the Stage for free.
